Model No.

MTWJ-100

MTWJ-150

MTWJ-175

MTWJ-200

Motor

Input: 3/4HP

Input: 1HP

Input: 1HP

Input: 2HP

Table size

900x130mm

1030x180mm

1030x210mm

1340x230mm

Cutter head speed

4400rpm/ 50hz , 5200rpm/ 60hz

Cutter knives Qty

3pcs

Cutter head Dia.

61mm

61mm

61mm

65mm

Fence tilt angle

45° in and out

Fence size

630x78mm

875x98mm

875x98mm

875x98mm

Cutting capacity

Width:102mm
Depth:3.175mm
Rabbeting: 12.7mm

Width:152mm
Depth:3.175mm
Rabbeting: 12.7mm

Width:175mm
Depth:3.175mm
Rabbeting: 12.7mm

Width:200mm
Depth:3.175mm
Rabbeting: 10mm

N.W/ G.W

65/ 70kgs

84/ 90kgs

98/ 105kgs

130/ 146kgs

Packing size(LxWxH)

960x440x260mm

1100x480x275mm

1100x545x285mm

1365x610x295mm

Qty/ 20'

260pcs

198pcs

160pcs

90pcs
