1.1 Saw

Max. cutting length

3200mm

Min. thickness of work piece

3mm

Dia. of saw blade

355x30mm

Dia. of scorer blade

120x20mm

Max. cutting thickness at 90 degree

100mm

Max. cutting thickness at 45 degree

70mm

Main saw speed

3700rpm

Scorer saw speed

8000rpm

Main saw motor power

4kw

Scorer saw motor power

0.75kw

1.2 Spindle moulder

Shaft Dia.

30mm

Useful shaft working length

85mm

Spindle speed

750/3500/6700r/min

Cutter rotating max. Dia.

140mm

Motor power

2.2kw

N.W

750kgs

Overall dimension

3360×3570×1160mm
